3.2V 277Ah-A

Type

Rated Capacity (Ah)

Rated voltage(V)

Energy Density

Weight

Dimension (mm)

Continuous discharge rate

LFP16Ah

16Ah

3.2

147Wh/kg

350g±5g

19.5mm x65mm x140mm

2C for 120s 3C for 10s

LFP86Ah

86Ah

3.2

125Wh/kg

Max. 2200g

47.7*173.9*132.5 (welding terminal) 47.7*173.9*142.5 (screw terminal)

3C for 60s

LFP92Ah

92Ah

3.22

135Wh/kg

Max. 2240g

29*174*207 (welding terminal) 29*174*217 screw terminal)

3C for 60s

LFP120Ah

120Ah

3.2

130Wh/kg

Max. 2950g

47.7*173.9*170.3 (welding terminal) 47.7*173.9*180.3 (screw terminal)

3C for 60s

LFP176Ah

176Ah

3.2

145Wh/kg

Max. 3984g

53.7*174.6*207.1 (welding terminal) 53.7*174.6*217.1 (screw terminal)

3C for 60s

LFP206Ah

206Ah

3.22

161Wh/kg

Max. 4200g

53.9*174.6*207.1 (welding terminal) 53.9*174.6*217.1 (screw terminal)

3C for 60s

LFP240Ah

240Ah

3.2

150Wh/kg

Max. 5220g

71.6*174.6*207.1 (welding terminal) 71.6*174.6*217.1 (screw terminal)

3C for 60s

LFP277Ah

277Ah

3.22

164Wh/kg

Max. 5620g

71.8*174.6*207.1 (welding terminal) 71.8*174.6*217.1 (screw terminal)

3C for 60s

NCM42Ah

42Ah

3.65

180Wh/kg

Max. 870g

26.8*148.3*98.25 (welding terminal) 26.8*148.3*108.25 (screw terminal)

3C for 60s

NCM53Ah

53Ah

3.72

220Wh/kg

Max. 1010g

26.85*149*101.75 (welding terminal) 26.85*149*111.75 (screw terminal)

3C for 60s

Item

Specification

Dimension (Welding terminal)

71.8mm x174.6mm x207.1mm

Dimension (Screw terminal)

71.8mm x174.6mm x217.1mm

Weight

Max.5220g

Min. capacity

277Ah (0.5C) @ 25°C

Min. energy

891Wh (0.5C) @ 25°C

SOC window

0〜100 %

Terminal

Welding/Screw terminal

Voltage

Max.

3.65 V

Nominal

3.20 V

Min.

2.50 V(>0°C) /2.00V(<0°C)

Energy density

Gravimetric

1640Wh/kg

Volumetric

357Wh/L

Temp. Condition

Operation (Charge)

0〜55°C

Operation (Discharge)

-20〜55°C

Storage

-30〜55°C

Self-Discharge Rate

Count after fresh cell need Standard Charge to 50%SOC and storage at 25±2°C for 3 month

<3%

Cycle Life

1C/1C, 80% DOD 25°C

3,000 cycles

1C/1C, 80% DOD 45°C

1,000 cycles

Service Life

35°C average temperature

5years/200000Km

Calendar Life

SOC 50%, 25°C

On going (10yrs est.)

Abuse test

overcharge, Over-discharge, Short, Heat

GB/T 31485-2015
